3 port Gigabit Fiber Optic Media Converter
12v 24v industrial switch with sfp
Introduction of fiber optic media converter
IM-FS120GE series is the 10/100/1000 Mbps industrial fiber switch,
operating temperature-40 ℃ to + 75 ℃, support wide voltage dual
power input, meet IP40 protection degree and EMC industrial grade
requirements, DIN rail installation, pass through dangerous
environmental certification and comply with FCC and CE standards.
The reliable industrial grade design could ensure continuous and
stable operation of the automation system.
Specification of Industrial Full Gigabit Switch
| Product Name | 10/100/1000Mbps Industrial Fiber Switch (1F+2TP) |
| Model No. | IM-FS120GE |
| Port | 1 x 1000Mpbs SFP port SM:1310nm/1550nm,20Km 1490nm/1550nm,40~120Km MM:1310nm,2Km 2x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing) |
| Switching features | Transmission mode:storage and forward System bandwidth:40Gbps (non-traffic jam) |
| Network media | 10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m) 100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m) SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km |
| LEDs | Power, network, fiber |
| Power supply | Input voltage:DC 9-52V No-load power:5W Reverse connection:support |
| Environment | Working temperature:-40°～ 75°C Storage temperature:-40°～ 85°C Working humidity:10%～90%,non-condensing Storage humidity:10%～95%,non-condensing |
| Industry Standards | EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN
61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6
(CS) Level 3,EN 61000-4-8 Traffic Control:NEMA-TS2 Vibration:IEC 60068-2-6 Freefall:IEC 60068-2-32 Shock:IEC 60068-2-27 Rail Traffic:EN 50121-4 |
| Safety | CE Mark ,commercial CE/LVD EN60950 |
| Mechanical information | Shell:Corrugated metal shell Safety class:IP40 Dimension: 113.8 x 93 x 34.9mm Mounting method:Din-rail mounting |
| Warranty | Replacement within 1year; 3 years repairing |
Application
Packing box of Din rail unmanaged switch:
- Put the product in an ESD Bag, then placed in PE foams with outer
carton packaging.
- The standard packing usually contains a main device, a warranty
card and a user manual.
- Packing box dimension for 1pc: 23*16.5*5.8cm
- 40pcs in a packing box of 67*33*47cm dimension.
FAQ:
1.Whats Your Main Products?
POE Switch,industrial POE Switch,Ethernet Switch, WDM, OTN, optical
bypass switch and other transmission series.
2.Which Payment Terms Do You Accept?
We Can Accept T/T, Paypal.
3.How Long Can I Expect To Get The Sample ?
Usually Within 3 Days But Depends On Your Requirements.
4.How About The Shipping ?
We Will Deliver The Goods With Internation Express Like
FEDEX,DHL,UPS,TNT And So On.
5.How About The After-sales Services?
Professional Services Team,24 Hours On Line.
